Introduction
- Composed of loading system,transmission system, measurement and control system, applicable to mechanical property test for sprial cylinder spring and various elastic components.
- Adopting motor loading, imported numerical control motor control system.
- Digital display load,deformation, loading speed, test times,etc.
Technical Specification
1) max.test force:2000N, min. Reading: 0.1N
2) relative accuracy of indicating value of load: ¡À1.0%
3) relative error of repeatability of indicating value of load: ¡Ü1.0%
4) effective test space: 500mm
5) min.reading of displacement: 0.01mm
6) diameter of upper and lower pressure platen: ¦µ110mm
7) moving speed of crosshead: 0.2-500mm/min
8) display and operation mode: dot-matrix LCD display and keyboard operation
9) voltage: 220VAC, 50Hz power: 0.4KW
10) dimension: 410*470*1150mm
11) weight: approx. 105kg.

|
